Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity

    Buy cheap Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity from wholesalers

    Buy cheap Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity from wholesalers
    • Buy cheap Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity from wholesalers

    Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity

    Ask Lasest Price
    Brand Name : TOPSPACK
    Model Number : TPW100L 200L 300L 500L 1000L 1500L 2000L 3000L
    Certification : CE SGS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10sets/month
    Delivery Time : 15~25 working days
    • Product Details
    • Company Profile

    Full Clean Paddle Mixer Machine AC208-415V Double Shaft High Uniformity

    CE certificate SUS304 powder double shaft paddle blender mixer machine


    Descriptive abstract

    Double shaft paddle mixer is called no gravity mixer, too; it is widely applied in mixing powder and powder, granular and granular, granular and powder, and few liquid; it is used for food, chemical, pesticide, feeding stuff, and battery ect.


    Main Features

    1. High active :Rotate reversely and throw materials to different angles,mixing time 1-3min.

    2. High uniformity:Compact design and rotated shafts be filled with hopper, mixing uniformity up to 99%.

    3. Low residue:Only 2-5mm gap between shafts and wall, open-type discharging hole.

    4. Zero leakage: Patent design and ensure the rotating axle & discharging hole w/o leakage.

    5. Full clean:Full weld and polishing process for mixing hopper, w/o any fastening piece like screw,nut.

    6. Nice profile: the whole machine is made by 100% stainless steel to make its profile elegant except bearing seat.


    Main Technical Data

    ModelTPW-300TPW-500TPW-1000TPW-1500TPW-2000TPW-3000
    Effective volume(L)3005001000150020003000
    Full volume(L)4206501350200026003800
    Loading Ratio0.6-0.8
    Turning speed(rpm)535345453939
    power5.57.5111518.522
    Total weight(kg)6609001380185023502900
    Total size1330*1130*10301480*1350*12201730*1590*13802030*1740*14802120*2000*16302420*2300*1780
    R(mm)277307377450485534
    Power supply3P AC208-415V 50/60Hz
